Bag Fill & Seal Line
material such as food, coffee, tea, electronic components, candy, grains, pills, plastic parts, and seed, just to mention a few. The compact affordable systems are ideal for small or start-up companies to get their product into the market with very little investment.
The sealer is available with either a hot air or band sealer, painted, stainless steel or in a washdown version. All the sealers are available in right to left or left to right configurations, so the scale can accommodate from either side.
The Tridyne Scales come in many different configurations, from single lane to multiple lanes with a single controller. Some of the scales can have split front feeders for difficult or irregular sized materials and multiple feeders per lane to ensure consistent, controlled uniform product flow, leading to the fastest most accurate weighment possible.
Features | Benefits |
No tool band change over: | Easy to maintain. |
Variable Speed: | Ease of matching conveyor speeds and flexibility. |
Closed Loop PID Temperature Control: | Accurate and consistent sealing temperature. |
Stainless steel exterior finish. |
|
Motorized Pedestal: | Adjust height with a touch of a button, simplifying multiple bag applications. |
TECHNICAL SPECIFICATIONS | |
| Bag Size Range: | All Bag Sizes. |
| Bag Materials: | Heat Sealable up to 12 mils. |
| Speed: | Up to 48 fpm. |
| Machine Handing: | Right to Left or Left to Right. |
| Electric Requirements: | 110 VAC, 1 PH, 60 Hz, 10 Amp 220 VAC, 1 PH, 50 Hz, 7 Amp CE Marked. |
| Pneumatic: | Not required on standard configuration Required for optional Jet Flow Trim Remover. |
Add-on Options
- Bag Top Trimmers
- Trim Removers 3" (76mm) or 5" (127mm)
- Automatic Infeed
- Bag Coders and Printers
- Customized Conveyors
- Washdown (IP65 or IP69K) and Corrosive Washdown
- Dedusters for difficult dusty environments
